Resource Description

A quick overview of what the resource offers.

#Links

Download

#Information

This is an easy-to-use solution to your prop alignment hell. With our sleek UI you can utilize inputs, history & presets to speed up your alignment for your props.

The entire project is the first effort to make a great alignment menu, and more updates to streamline the process will come in the future once I am available to work on it.

#Features

Sleek & modern UI for all inputs along with smart validation.
Supports multiple props.
Offset & rotation to player.
Particle alignments offset from the prop.
Possible to integrate into resources using exports, provide & return alignments with ease.
Plays animation for realistic interactions, with different speeds.
Server-wide presets to load pre-defined configurations.
Export & import presets to share.
Client-sided history to save your recent configurations.
Visualize the data in Lua & JSON format for easy implementation.

#Get Started

Open the menu via the command in the config, /palign by default.
Start filling out the information, or go to Presets to import a base to get started from.

#Demo Presets

You can paste these presets into the import input, press the import button and try them out.

#Plate With Curry

json
{
    "label": "Curry (Dual Prop)",
    "data": {
	"dict": "anim@scripted@island@special_peds@pavel@hs4_pavel_ig5_caviar_p1",
        "clip": "base_idle",
        "props": [
            {"rotation": {"x": 0, "y": 0, "z": -50}, "prop": "prop_cs_plate_01", "bone": 60309, "offset": {"x": 0, "y": 0, "z": 0}},
            {"rotation": {"x": 180, "y": 180, "z": 0}, "prop": "prop_cs_fork", "bone": 28422, "offset": {"x": 0, "y": 0, "z": 0}}
        ]
    }
}

#Water Bottle

json
{
    "label": "Water Bottle",
    "data": {
	"dict": "mp_player_intdrink",
        "clip": "loop_bottle",
        "props": [
            {"rotation": {"x": -103.202, "y": -68.066, "z": 2.814}, "prop": "prop_ld_flow_bottle", "bone": 18905, "offset": {"x": 0.122, "y": -0.038, "z": 0.033}}
        ]
    }
}

#Burger

json
{
    "label": "Burger",
    "data": {
        "dict": "mp_player_inteat@burger",
        "clip": "mp_player_int_eat_burger",
        "props":[
            {"bone": 18905, "model": "prop_cs_burger_01", "rotation": {"x": 31.162, "y": 136.033, "z": -13.003}, "prop": "prop_cs_burger_01", "offset": {"x": 0.144, "y": 0.027, "z": 0.040}}
        ]
    }
}

#Soda Can (Sprunk)

json
{
    "label":"Soda Can",
    "data": {
        "dict":"mp_player_intdrink",
        "clip":"loop_bottle",
        "props": [
            {"bone": 18905,"model": "prop_ld_can_01b", "rotation": {"x":-103.202,"y":-68.066,"z":2.814}, "prop": "prop_ld_can_01b", "offset":{"x": 0.122, "y": -0.007, "z": 0.035}}
        ]
    }
}

#Cigarette

json
{
    "label": "Cigarette & Particles",
    "data": {
        "dict": "amb@world_human_aa_smoke@male@idle_a",
        "clip": "idle_a",
        "props": [
            {"bone": 64097, "prop": "ng_proc_cigarette01a", "rotation": {"x": 100, "y": 0, "z": 100}, "offset": {"x": 0.02, "y": 0.02, "z": -0.008},
                "particles": [
                    {"clip": "exp_grd_bzgas_smoke", "size": 1, "dict": "core", "offset": {"x": -0.068, "y": 0.0, "z": 0.0}}
                ]
            }
        ]
    }
}
